These pressure/vacuum modules are used to handle components by vacuum. Two adjustment screws enable to precisely and independently adjust pressure and vacuum flows.
Different digital or analog pressure switches are available and indicate vacuum fluctuations and picking up of components.
An innovative design makes the new generation units 5 times more economical in terms of air consumption than former generation units. They are also smaller. They can be easily integrated and cleaning is quick and simple.
These units are also available without vacuum generator, for direct connection to external vacuum network (PV212 and PV312).
